GP609 Shielded PVC Drag Chain Cable 12M Cycles for EMI Protection | GTFI

Model: CBL02 ⭐ High Flexibility In Stock

High-flex design for continuous motion
Excellent resistance to oil and abrasion
CE/RoHS/UL certified
Custom lengths and terminations available

1 Unit 1 Unit 15-25 Days 15-25 Days Shipping: FOB Shanghai / Shenzhen 12 Months 12 Months Spare Parts: Available

GTFI GP609 shielded high-flex PVC drag chain cable, 12 million bending cycles, tinned copper braid shielding. Ideal for applications requiring EMI protection in woodworking and conveyors.

Model: GP609

Sheath: PVC

Flex Life: 12M cycles

Shielding: Tinned copper braid

Temp Range: -20°C ~ 80°C

Rated Voltage: 300/500V

30+ Countries Export CE/RoHS/UL Certified Factory Tested 24/7 Support

Technical Data

Core Specifications

Key parameters at a glance — see if this cable fits your application needs.

ModelGP609

SheathPVC

Flex Life12M cycles

ShieldingTinned copper braid

Temp Range-20°C ~ 80°C

Rated Voltage300/500V

Test Voltage2000V

Min Bending Radius7–10×D (moving)

Max Speed1 m/s (overhead)

CertificationsCE, RoHS

Overview

Technical Overview

GTFI GP609 shielded high-flex PVC drag chain cable, 12 million bending cycles, tinned copper braid shielding. Ideal for applications requiring EMI protection in...

The GP609 Shielded PVC Drag Chain Cable 12M Cycles for EMI Protection | GTFI is specified for the applications and operating conditions shown on this page. Key configuration data includes Model: GP609, Sheath: PVC, Flex Life: 12M cycles, Shielding: Tinned copper braid, Temp Range: -20°C ~ 80°C, Rated Voltage: 300/500V.

Typical applications listed for this model include Woodworking machinery, Conveyor systems, Industrial control system..., Automation equipment, CNC machines, Packaging machinery. For procurement, confirm the required model, electrical or mechanical specifications, cable construction, and application conditions against the technical data above.

Key Technical Features

High Flexibility — 12M cycles bending cycles for continuous motion applications.
Durable Sheath — PVC provides excellent resistance to oil, abrasion, and wear.
Reliable Signal Integrity — Tinned copper braid shielding protects against EMI/RFI interference.
Wide Temperature Range — -20°C ~ 80°C for diverse operating environments.
Global Compliance — CE, RoHS, and UL certified for international markets.
Custom Solutions — custom lengths, colors, and terminations available.

#IndustrialCable #DragChainCable #RobotCable #Automation #ULCertified

Why Choose GTFI

Technical Advantages

Four reasons to choose GTFI industrial cables for your automation needs.

EMI Protection

Tinned copper braid shielding prevents electromagnetic interference.

Long Flex Life

12 million bending cycles for long service life.

Reliable Signal

Shielded design ensures clean signal transmission in noisy environments.

CE/RoHS Certified

Compliant with international quality standards.

Applications

Where This Cable Works Best

Six common use cases for this industrial cable.

Woodworking machinery

Conveyor systems

Industrial control system...

Automation equipment

CNC machines

Packaging machinery

How It Works

Working Principle

Simple, efficient, and reliable three-step cable operation process.

Cable Installation

Install the shielded cable in the drag chain with proper grounding for effective EMI protection.

Movement

The cable moves with the machinery while the shield protects against interference.

Signal Transmission

The shielded cable transmits control signals reliably without EMI distortion.

Real Installations

Installation Cases

See how GTFI industrial cables are installed in real projects.

IDC Ribbon Cable

IDC ribbon cable for industrial control, development boards,...

JTY (Reel Round)

Low-voltage reel round cable for cranes and port equipment. ...

New Energy HV Distribution Har...

New energy high-voltage distribution harness for EV systems....

FAQ

Frequently Asked Questions

Quick answers to the most common questions about our industrial cables.

What is the difference between G610 and GP609?

GP609 has tinned copper braid shielding for EMI protection.

What is the flex life?

12 million bending cycles.

What is the temperature range?

-20°C to 80°C fixed, -5°C to 70°C moving.

Is the shield suitable for EMC compliance?

Yes, the tinned copper braid helps meet EMC requirements.

What certifications does it have?

CE and RoHS.
